Widely known for its 250-like agility and 450-like power, the KTM 350 EXC-F has built a reputation for versatility. But, that doesn’t mean it’s compromised. Gaining instant recognition on its arrival in 2012, it has become a class-leading model due to its sheer rideability and competitive power output. For 2025 it brings an all-new attitude to the fray, charging toward the limit with next-level ability.
Weight | 107.4 kg |
---|---|
Brand | KTM |
Year | |
PRIMARY DRIVE | |
TRANSMISSION | 6-speed |
SECONDARY GEAR RATIO | |
STARTER | Electric starter |
STROKE | 57.5 mm |
BORE | 88 mm |
CLUTCH | Wet, DDS multi-disc clutch, Brembo hydraulics |
Compression ratio | |
DISPLACEMENT | 349.7 cm³undefined |
EMS | Keihin EMS |
DESIGN | 1-cylinder, 4-stroke engine |
Fuel-mixture generation | |
Weight Without Fuel | |
TANK CAPACITY (APPROX.) | 8.5 l |
Wheelbase | |
FRONT BRAKE DISC DIAMETER | 260 mm |
REAR BRAKE DISC DIAMETER | 220 mm |
FRONT BRAKE | Disc brake |
REAR BRAKE | Disc brake |
CHAIN | 520 X-Ring |
FRAME DESIGN | Central double-cradle-type 25CrMo4 steel |
FRONT SUSPENSION | WP XACT-USD, Ø 48 mm |
REAR SUSPENSION | WP XPLOR shock absorber with PDS |
GROUND CLEARANCE | 347 mm |
SEAT HEIGHT | 963 mm |
STEERING HEAD ANGLE | 63.9 ° |
SUSPENSION TRAVEL (FRONT) | 300 mm |
SUSPENSION TRAVEL (REAR) | 310 mm |
